import numpy as np
from bokeh.plotting import figure, save, output_file
from bokeh.models import (
ColumnDataSource, HoverTool, CustomAction, CustomJS,
DataTable, TableColumn, NumberEditor, StringEditor, TextInput, Button
)
from bokeh.layouts import column, row
# ---- Generate random data for bar plot ----
months = ['Jan','Feb','Mar','Apr','May','Jun','Jul','Aug','Sep','Oct','Nov','Dec']
values = [151,168,193,223,240,245,238,221,195,170,154,150]
bar_data_source = ColumnDataSource(dict(x=months, y=values))
# ---- Bar plot ----
bar_plot = figure(
width=800, height=500, title='Interactive Bar Plot with Editable Data',
x_range=bar_data_source.data["x"]
)
bar_plot.xaxis.axis_label = 'Categories'
bar_plot.yaxis.axis_label = 'Values'
bars = bar_plot.vbar(
x='x', top='y', width=0.8, source=bar_data_source,
fill_color='steelblue', line_color='black', alpha=0.8,
hover_fill_color='navy', hover_line_color='white'
)
bar_plot.add_tools(HoverTool(tooltips=[('Category', '@x'), ('Value', '@y')], renderers=[bars]))
# ---- Data Table ----
columns = [
TableColumn(field="x", title="Category (X)", editor=StringEditor()), # Accepts text!
TableColumn(field="y", title="Value (Y)", editor=NumberEditor())
]
data_table = DataTable(source=bar_data_source, columns=columns, width=400, height=300, editable=True)
# Input fields for adding new data
new_x_input = TextInput(value="", title="New Category:", width=120)
new_y_input = TextInput(value="", title="New Value:", width=120)
add_button = Button(label="Add Data Point", button_type="success", width=120)
# Initially hide the table and inputs
data_table.visible = False
new_x_input.visible = False
new_y_input.visible = False
add_button.visible = False
# ---- Custom toolbar action for data table ----
table_callback = CustomJS(
args=dict(
data_table=data_table,
new_x_input=new_x_input,
new_y_input=new_y_input,
add_button=add_button,
),
code="""
const currently_visible = data_table.visible;
data_table.visible = !currently_visible;
new_x_input.visible = !currently_visible;
new_y_input.visible = !currently_visible;
add_button.visible = !currently_visible;
"""
)
table_action = CustomAction(
description="Toggle Data Table",
callback=table_callback
)
bar_plot.add_tools(table_action)
# ---- CustomJS callback for updating bar plot when data changes ----
update_bar_callback = CustomJS(
args=dict(
source=bar_data_source,
plot=bar_plot
),
code="""
// Update bar plot x_range to accommodate new data
const new_x_values = source.data['x'].map(x => x.toString());
plot.x_range.factors = new_x_values;
"""
)
# ---- CustomJS callback for adding new data point ----
add_data_callback = CustomJS(
args=dict(
source=bar_data_source,
x_input=new_x_input,
y_input=new_y_input,
plot=bar_plot
),
code="""
try {
const new_x = x_input.value; // Accept as string!
const new_y = parseFloat(y_input.value);
if (!new_x || isNaN(new_y)) {
return;
}
// Get current data as arrays
const current_x = Array.from(source.data['x']);
const current_y = Array.from(source.data['y']);
// Add new point
current_x.push(new_x);
current_y.push(new_y);
// Update data source
source.data = {
'x': current_x,
'y': current_y
};
// Update bar plot x_range
const new_x_values = current_x.map(x => x.toString());
plot.x_range.factors = new_x_values;
// Clear input fields
x_input.value = "";
y_input.value = "";
} catch (error) {
console.log("Error adding data point:", error);
}
"""
)
# Attach callbacks
bar_data_source.js_on_change('data', update_bar_callback)
add_button.js_on_click(add_data_callback)
# ---- Layout ----
input_row = row(new_x_input, new_y_input, add_button)
table_section = column(data_table, input_row)
layout = row(
bar_plot,
table_section
)
# Save to HTML file
output_file("interactive_bar_plot_with_table.html")
save(layout)
